SD320 Series Battery Disconnect Switches

Features: * Safely rupture full load currents in the event of an emergency * Can be used in high-side or low-side applications * Large DC rating up to 500A * SAE J1455 compliant for harsh environment * Optional lock-out/tag-out (LOTO) satisfying OSHA requirements * Black or gray thermoplastic housing with a UL 94 V-0 rating * IPX8 rated	Installation dimensions:
Specifications: Rated Voltage: 6/12/24/36V DC Short-time Current: Large Terminal 36VDC 1000A (On 12s, Off 5min) Ignition Protection: UL 94V-0 Opearting Temp.: -40 °C to 85 °C [-40 °F to 185 °F] Circuitry: DPST Protection Level: IP68

TRADEMARK INFORMATION:
All trademarks, trade names, or logos mentioned or used are the property of their respective owners.



TRADEMARK INFORMATION:
All trademarks, trade names, or logos mentioned or used are the property of their respective owners.

TYPE:SD320-M-P View Details

TYPE:SD-LK View Details
